Product information
(Unit：mm)
Contact us for products- 1400-0198
- 58 series
- Terminal For AV Wire
- 2.8mm(110)
| Sealed/Unsealed | unsealed |
|---|---|
| Male/Female | M |
| Tab Size | 2.8mm(110) |
| Size | S |
| Mating parts |
1400-0196(58 series) |
| Applicable wire size |
|
|---|---|
| Cable overall diameter (mm) | 1.4-2.6 |
| Materials | Brass |
| Surface treatment | Tin-plated |
| Thickness (mm) | 0.4 |
| (tab thickness) | 0.8 |
| Contact resistance |
|
| Leak current | 1mA Max. |
| Insulation resistance | 100MΩ Min. |
